Product Introduction
Temperature and humidity collection frequency: 2s/time; data upload frequency: 1s~10000s/time adjustable; device parameters are configured through the network port, simple and convenient;
Built-in alarm function, with adjustable upper and lower alarm limits and hysteresis values, built-in one buzzer, and one external sound and light alarm (optional);
Adapts to DC7~30V wide voltage power supply, Swiss-imported original high-quality temperature and humidity measurement unit, probe can be extended, probe cable up to 30 meters.
| Power supply | DC 7~30V | |
| Power consumption | 0.7W | |
| Communication interface | RJ45 network port, TCP data upload, supports static IP address, DHCP automatic IP address acquisition, supports cross-gateway, DNS domain name resolution | |
| Class A accuracy | Humidity | ±2%RH(60%RH,25℃) |
| Temperature | ±0.4℃（25℃） | |
| Class B accuracy (default) | Humidity | ±3%RH(60%RH,25℃) |
| Temperature | ±0.5℃（25℃） | |
| Transmitter circuit operating temperature and humidity | -20℃~+60℃, 0%RH~95%RH (non-condensing) | |
| Probe Operating Temperature and Humidity | -40℃~+80℃ (default, other ranges customizable), 0-100%RH | |
| Temperature Display Resolution | 0.1℃ | |
| Humidity Display Resolution | 0.1%RH | |
| Temperature and humidity refresh time | 1s | |
| Long-term stability | Humidity | ≤1%RH/y |
| Temperature | ≤0.1℃/y | |
| Response time | Humidity | ≤8s (1m/s wind speed) |
| Temperature | ≤25s (1m/s wind speed) | |
| Data upload time | 5s/time (default, 1s~10000s adjustable) | |
Main Application Areas
- Server Room Monitoring — Monitor temperature and humidity in data centers and server rooms to prevent overheating and ensure optimal operating conditions.
- Warehouse & Storage — Track environmental conditions in warehouses storing sensitive goods such as pharmaceuticals, food, and electronics.
- Greenhouse & Agriculture — Monitor temperature and humidity in greenhouses and agricultural facilities to optimize crop growth and yield.
- Industrial Automation — Integrate into industrial control systems for real-time environmental monitoring in factories and production lines.
- Laboratory & Research — Provide precise temperature and humidity data for laboratories and research facilities requiring stable conditions.
Keywords：ethernet temperature transmitter, humidity transmitter, data logger, industrial transmitter, temperature humidity sensor, ethernet data logger, RS-WS-ETH-6, remote monitoring
