Near-Infrared Thickness Gauge Analyzer Online Thickness Analysis for Biaxially Oriented Films - SKA/JHW-CHY
Measurement performance
• Measurement range: 0.01～10mm (customizable)
• Measurement accuracy: ±0.5%FS
• Resolution: 0.001mm
• Sampling frequency: 10～100Hz adjustable
• Spot diameter: 1～5mm
• Measured materials: plastic film, rubber, coatings, non-woven fabrics, etc.
Environmental Parameters
• Operating temperature: 0～50℃
• Storage temperature: -20～70℃
• Ambient humidity: 10%～85%RH, non-condensing
• Protection rating: IP65
Product Introduction
Near-Infrared Thickness Gauge Analyzer Online Thickness Analysis for Biaxially Oriented Films - Product Overview
The near-infrared thickness gauge analyzer is a non-contact thickness detection device used for online thickness analysis of biaxially oriented films. Search keywords: near-infrared thickness gauge analyzer, online thickness analysis for biaxially oriented films, near-infrared thickness gauge. The analyzer is fixedly installed on biaxially oriented film production lines and can continuously detect the thickness of BOPP, BOPET, and BOPA films, suitable for the packaging and electronic film industries. In online thickness analysis of biaxially oriented films, the near-infrared thickness gauge analyzer can reflect thickness changes in real time, helping enterprises control product quality and reduce waste and raw material loss caused by thickness fluctuations.
Near-Infrared Thickness Gauge Analyzer Online Thickness Analysis for Biaxially Oriented Films - Working Principle
The near-infrared thickness gauge analyzer utilizes the characteristics of near-infrared light being absorbed and reflected when penetrating films, calculating film thickness by measuring changes in light intensity at specific wavelengths. In online thickness analysis of biaxially oriented films, the near-infrared thickness gauge analyzer adopts a non-contact measurement method that does not damage the film surface, with fast response speed, enabling millisecond-level measurement. The analyzer supports 4-20mA, RS485, and Modbus outputs, can be connected to PLC, DCS, and production line control systems, and features automatic calibration and fault self-diagnosis functions.
Near-Infrared Thickness Gauge Analyzer Online Thickness Analysis for Biaxially Oriented Films - Application Scenarios
The near-infrared thickness gauge analyzer is widely used in BOPP, BOPET, and BOPA film production lines. In online thickness analysis of biaxially oriented films, the near-infrared thickness gauge analyzer can be fixedly installed at the extruder outlet, longitudinal stretching zone, transverse stretching zone, and before winding to collect thickness data in real time. The analyzer can be linked with extruders, stretching machines, and winding systems to achieve automatic thickness adjustment. For large film production lines, the near-infrared thickness gauge analyzer can also form a multi-point monitoring network, uniformly uploaded to the control room.
Near-Infrared Thickness Gauge Analyzer Online Thickness Analysis for Biaxially Oriented Films - Technical Advantages
The near-infrared thickness gauge analyzer has advantages such as non-contact operation, high precision, and fast response. In online thickness analysis of biaxially oriented films, the near-infrared thickness gauge analyzer adopts a long-life light source and anti-contamination optical design, suitable for long-term operation. The analyzer supports remote calibration and fault self-diagnosis, making maintenance convenient. When selecting a near-infrared thickness gauge analyzer, attention should be paid to measurement range, precision, response time, protection rating, and output signals to ensure it meets the requirements for online thickness analysis of biaxially oriented films.
