Near-Infrared Thickness Measurement System Coated Fabric Thickness Online Measurement - SKA/JHW-CHY
Measurement performance
• Measurement range: 0.01～10mm (customizable)
• Measurement accuracy: ±0.5%FS
• Resolution: 0.001mm
• Sampling frequency: 10～100Hz adjustable
• Spot diameter: 1～5mm
• Measured materials: plastic film, rubber, coatings, non-woven fabrics, etc.
Environmental Parameters
• Operating temperature: 0～50℃
• Storage temperature: -20～70℃
• Ambient humidity: 10%～85%RH, non-condensing
• Protection rating: IP65
Product Introduction
Near-Infrared Thickness Measurement System Coated Fabric Thickness Online Measurement - Product Overview
The near-infrared thickness measurement system is a non-contact thickness measurement system used for coated fabric thickness online measurement. Search keywords: near-infrared thickness measurement system, coated fabric thickness online measurement, near-infrared thickness gauge. The system is fixedly installed on coated fabric production lines and can continuously measure the thickness of coated fabric, waterproof fabric, and tarpaulin, making it suitable for the textile and outdoor products industries. In coated fabric thickness online measurement, the near-infrared thickness measurement system can reflect thickness changes in real time, helping enterprises control product quality and reduce coating waste.
Near-Infrared Thickness Measurement System Coated Fabric Thickness Online Measurement - Working Principle
The near-infrared thickness measurement system utilizes the characteristics of near-infrared light being absorbed and reflected when penetrating coated fabric, and calculates the coated fabric thickness by measuring the change in light intensity at specific wavelengths. In coated fabric thickness online measurement, the near-infrared thickness measurement system adopts a non-contact measurement method, does not damage the coating surface, and has a fast response speed. The system supports 4-20mA, RS485, and Modbus outputs, can be connected to PLC, DCS, and coating production line control systems, and has automatic calibration and fault self-diagnosis functions.
Near-Infrared Thickness Measurement System Coated Fabric Thickness Online Measurement - Application Scenarios
The near-infrared thickness measurement system is widely used in coated fabric, waterproof fabric, and tarpaulin production lines. In coated fabric thickness online measurement, the near-infrared thickness measurement system can be fixedly installed after the coating head, before drying, and before winding to collect thickness data in real time. The system can be linked with the coating head, dryer, and traction system to achieve automatic thickness adjustment. For large coated fabric production lines, the near-infrared thickness measurement system can also form a multi-point monitoring network and upload data uniformly to the control room.
Near-Infrared Thickness Measurement System Coated Fabric Thickness Online Measurement - Technical Advantages
The near-infrared thickness measurement system has the advantages of being non-contact, high precision, and fast response. In coated fabric thickness online measurement, the near-infrared thickness measurement system adopts a long-life light source and anti-contamination optical design, making it suitable for long-term operation. The system supports remote calibration and fault self-diagnosis, and is easy to maintain. When selecting a near-infrared thickness measurement system, attention should be paid to the measurement range, accuracy, response time, protection rating, and output signal to ensure it meets the needs of coated fabric thickness online measurement.
