Near-Infrared Thickness Gauge Online Rubber Sheet Thickness Measurement - SKA/JHW-CHY
Measurement performance
• Measurement range: 0.01～10mm (customizable)
• Measurement accuracy: ±0.5%FS
• Resolution: 0.001mm
• Sampling frequency: 10～100Hz adjustable
• Spot diameter: 1～5mm
• Measured materials: plastic film, rubber, coatings, non-woven fabrics, etc.
Environmental Parameters
• Operating temperature: 0～50℃
• Storage temperature: -20～70℃
• Ambient humidity: 10%～85%RH, non-condensing
• Protection rating: IP65
Product Introduction
Near-Infrared Thickness Gauge Online Rubber Sheet Thickness Measurement - Product Overview
Near-infrared thickness gauge is a non-contact thickness measurement device used for online rubber sheet thickness measurement. Search keywords: near-infrared thickness gauge, online rubber sheet thickness measurement, near-infrared thickness meter. The gauge is fixedly installed on rubber sheet production lines and can continuously measure the thickness of rubber sheets, rubber belts, and rubber hoses, suitable for the rubber and tire industries. In online rubber sheet thickness measurement, the near-infrared thickness gauge can reflect thickness changes in real time, helping enterprises control product quality and reduce raw material waste.
Near-Infrared Thickness Gauge Online Rubber Sheet Thickness Measurement - Working Principle
Near-infrared thickness gauge utilizes the characteristics of near-infrared light being absorbed and reflected when penetrating rubber materials, calculating rubber sheet thickness by measuring light intensity changes at specific wavelengths. In online rubber sheet thickness measurement, the near-infrared thickness gauge adopts a non-contact measurement method that does not damage the rubber surface and has fast response speed. The gauge supports 4-20mA, RS485, and Modbus outputs, can be connected to PLC, DCS, and production line control systems, and features automatic calibration and fault self-diagnosis functions.
Near-Infrared Thickness Gauge Online Rubber Sheet Thickness Measurement - Application Scenarios
Near-infrared thickness gauge is widely used in rubber sheet, rubber belt, rubber hose, and tire production lines. In online rubber sheet thickness measurement, the near-infrared thickness gauge can be fixedly installed at the calender outlet, cooling line, and before winding to collect thickness data in real time. The gauge can be linked with the calender, traction system, and winding system to achieve automatic thickness adjustment. For large rubber production lines, the near-infrared thickness gauge can also form a multi-point monitoring network, uniformly uploaded to the control room.
Near-Infrared Thickness Gauge Online Rubber Sheet Thickness Measurement - Technical Advantages
Near-infrared thickness gauge features non-contact operation, high precision, and fast response. In online rubber sheet thickness measurement, the near-infrared thickness gauge adopts long-life light sources and contamination-resistant optical design, suitable for long-term operation. The gauge supports remote calibration and fault self-diagnosis, making maintenance convenient. When selecting a near-infrared thickness gauge, attention should be paid to measurement range, precision, response time, protection rating, and output signals to ensure it meets online rubber sheet thickness measurement requirements.
