Near-Infrared Thickness Measurement Transmitter Module Online Thickness Detection of Polystyrene Sheets - SKA/JHW-CHY
Measurement performance
• Measurement range: 0.01～10mm (customizable)
• Measurement accuracy: ±0.5%FS
• Resolution: 0.001mm
• Sampling frequency: 10～100Hz adjustable
• Spot diameter: 1～5mm
• Measured materials: plastic film, rubber, coatings, non-woven fabrics, etc.
Environmental Parameters
• Operating temperature: 0～50℃
• Storage temperature: -20～70℃
• Ambient humidity: 10%～85%RH, non-condensing
• Protection rating: IP65
Product Introduction
Near-Infrared Thickness Measurement Transmitter Module Online Thickness Detection of Polystyrene Sheets - Product Overview
The near-infrared thickness measurement transmitter module is a non-contact thickness detection device used for online thickness detection of polystyrene sheets. Search keywords: near-infrared thickness measurement transmitter module, online thickness detection of polystyrene sheets, near-infrared thickness gauge. The module is fixedly installed on polystyrene sheet production lines and can continuously detect the thickness of PS sheets, HIPS sheets, and EPS sheets, suitable for the packaging and building materials industries. In online thickness detection of polystyrene sheets, the near-infrared thickness measurement transmitter module can reflect thickness changes in real time, helping enterprises control product quality and reduce raw material waste.
Near-Infrared Thickness Measurement Transmitter Module Online Thickness Detection of Polystyrene Sheets - Working Principle
The near-infrared thickness measurement transmitter module utilizes the absorption and reflection characteristics of near-infrared light when penetrating polystyrene sheets, and calculates sheet thickness by measuring changes in light intensity at specific wavelengths. In online thickness detection of polystyrene sheets, the near-infrared thickness measurement transmitter module adopts a non-contact measurement method that does not damage the sheet surface and has fast response speed. The module supports 4-20mA, RS485, and Modbus outputs, and can be connected to PLC, DCS, and PS sheet production line control systems, featuring automatic calibration and fault self-diagnosis functions.
Near-Infrared Thickness Measurement Transmitter Module Online Thickness Detection of Polystyrene Sheets - Application Scenarios
The near-infrared thickness measurement transmitter module is widely used in PS sheet, HIPS sheet, and EPS sheet production lines. In online thickness detection of polystyrene sheets, the near-infrared thickness measurement transmitter module can be fixedly installed at the extruder outlet, calender, and before winding to collect thickness data in real time. The module can be linked with the extruder, calender, and winding system to achieve automatic thickness adjustment. For large-scale PS sheet production lines, the near-infrared thickness measurement transmitter module can also form a multi-point monitoring network and upload data uniformly to the control room.
Near-Infrared Thickness Measurement Transmitter Module Online Thickness Detection of Polystyrene Sheets - Technical Advantages
The near-infrared thickness measurement transmitter module has advantages such as non-contact, high precision, and standard output. In online thickness detection of polystyrene sheets, the near-infrared thickness measurement transmitter module adopts a long-life light source and anti-contamination optical design, making it suitable for long-term operation. The module supports remote calibration, fault self-diagnosis, and HART communication, making maintenance convenient. When selecting a near-infrared thickness measurement transmitter module, attention should be paid to the measurement range, accuracy, response time, protection rating, and output signal to ensure it meets the requirements for online thickness detection of polystyrene sheets.
