Coating Thickness Gauge - Ux-720
The Ux-720 combines a micro-motion platform with a high-definition CCD, with knob adjustment designed on the outside of the housing, making it simple and convenient to observe and adjust the moving position.
The application of X-ray fluorescence technology for coating thickness testing improves the inspection conditions for mass-produced electroplated products. Its non-destructive, fast, and more accurate characteristics enhance the quality assurance in the electronics and semiconductor industries.
The Ux-720 coating thickness gauge adopts Huawei's patented FlexFP-Multi technology. It is no longer limited by standard samples, and can directly test the coating thickness of samples without coated standards. The test results are scientifically verifiable.
Product Introduction
I. Description of Coating Thickness Gauge Ux-720:
The Ux-720 is a new generation of domestically produced professional coating thickness gauge. It adopts a high-resolution Si-PIN (or SDD silicon drift detector), providing good measurement accuracy and results. With FlexFP-Multi technology, whether it is quality control during production, or random inspection and material performance testing, we provide a friendly experience and meet testing needs.
II. Coating Thickness Gauge Ux-720Features:
The Ux-720 combines a micro-motion platform with a high-definition CCD, with knob adjustment designed on the outside of the housing, making it simple and convenient to observe and adjust the moving position.
The application of X-ray fluorescence technology for coating thickness testing improves the inspection conditions for mass-produced electroplated products. Its non-destructive, fast, and more accurate characteristics enhance the quality assurance in the electronics and semiconductor industries.
The Ux-720 coating thickness gauge adopts Huawei's patented FlexFP-Multi technology. It is no longer limited by standard samples, and can directly test the coating thickness of samples without coated standards. The test results are scientifically verifiable.
III. Coating Thickness Gauge Ux-720 Product Specifications:
Thickness Measurement Technology: X-ray fluorescence thickness measurement technologyTest Sample Types: Metal coatings, alloy coatings
Measurement Lower Limit: 0.003um
Measurement Upper Limit: 30-50um (determined by material elements)
Number of Measurement Layers: 10 layers
Measurement Time: 30-120 seconds
Detector Type: Si-PIN, electrically cooled
Detector Resolution: 145eV
High Voltage Range: 0-50KV, 50W
X-ray Tube Parameters: 0-50KV, 50W, side window type
X-ray Tube Target Material: Mo target
Filters: 3 types, automatic switching
CCD Observation: 2.6 million pixels
Micro-Motion Range: XY 15mm
Input Voltage: AC220V, 50/60Hz
Test Environment: Non-vacuum conditions
Data Communication: USB 2.0 mode
Collimators: 1mm, 2mm, 4mm
Software Method: FlexFP-Multi
Work Area Opening: Customizable work area
Sample Chamber: 330x360x100mm
