Color Sensor Chip - WH3620

WH3620 is a color-based light-to-digital converter that combines photodiodes, current amplifiers, analog circuits, and digital signal processors.

WH3620 provides red, green, blue, white, and infrared light sensing. Each channel outputs simultaneously in parallel, offering good illuminance and correlated color temperature performance under different lighting conditions such as white LED, CWF, TL84, D65, Illuminant A, and horizon. It can operate from darkness to direct sunlight, with a selectable detection range of approximately 70 dB.

WH3620 features programmable interrupt with high/low thresholds.

1. Features of Ambient Light Sensor Chip - WH3620:

I2C interface (fast mode up to 400 kHz/s)
Power supply voltage range from 2.4V to 3.6V
Operating temperature from -40°C to +85°C
Package-level trimming
Power-on reset and power-off reset
Wait time function
Parallel output of R, G, B, W, IR five channels
Fluorescent flicker immunity
Selectable analog gain
Selectable resolution (up to 16 bits)
High sensitivity at low illuminance
Detection range for high illuminance
High accuracy LUX & CCT

2. Applications of Ambient Light Sensor Chip - WH3620:

Mobile devices - phones, tablets, color matching devices

Consumer devices-LCD TVs, digital cameras, toys

Computing devices-Laptops, LCD monitors

Smart lighting -Ceiling lights, panel lights
