Comparator - MS761
Input offset voltage: 0.2mV, maximum 1mV
Input bias current: 0.2pA
Propagation delay: 120ns
Low power consumption: 300μA
Common-mode rejection ratio (CMRR): 100dB
Power supply rejection ratio (PSRR): 110dB
Push-pull output
Operating temperature range: -40℃ ~ 125℃
Operating voltage range: 2.7V ~ 5V
Product Introduction
MS761/762is a low-noise, low input offset voltage high-precision comparatorDevice, typical input offset voltage at room temperature is200μVover the entire temperature rangerelativelymaximumis1mV。MS761With a shutdown pin, the entire device can be turned off to reduce current consumption.MS761/762hasCMOSinput and push-pull output, with very low bias current and verylarge input impedance, no external pull-up resistor required.
I. Features of Comparator-MS761:
Input offset voltage: 0.2mV,relativelyup to 1mV
Input bias current: 0.2pA
Propagation delay: 120ns
Low power consumption: 300μA
Common-mode rejection ratio (CMRR): 100dB
Power supply rejection ratio (PSRR): 110dB
Push-pull output
Operating temperature range: -40℃ ~ 125℃
Operating voltage range: 2.7V ~ 5V
II. Applications of Comparator-MS761：
