Product Introduction
I.CR5410SHall Effect Current Sensor Description:
The CR5410 series AC/DC Hall Effect current sensors can provide a bipolar output that proportionally reflects the current input waveform. These devices are specifically used in applications such as multi-mode current detection.
II.CR5410SHall Effect Current Sensor Features:
Basic Accuracy: 1%
Calibration: RMS measurement, DC
Thermal Drift: 500 ppm /°C
Operating Temperature: 0°C to +60°C
Pollution Degree: 2
Insulation Voltage: 2500 VDC
Altitude: 2000m max.
Frequency Range: DC to DC and AC 20 Hz - 4 kHz
MTBF: 100K hours
Supply Voltage: 24 VDC ±10%
Output Load: 2KΩ or greater
Response Time: 0.25ms max
III.CR5410SHall Effect Current Sensor Applications
Welding machines, inverters, UPS power supplies, inverters, electric vehicles, electric locomotives, power stations, wind power generation,Robots, ground fault detectors, and other industrial control automation fields
