Current Monitoring Switch – Adjustable Trip – H308 - H308
Specifications:
Sensor Power: Induced from monitored conductor
Insulation Rating: 600VAC RMS (UL), 300VAC RMS (CE)
Frequency Range: 50/60 Hz
Temperature Range: -15° to 60°C
Humidity Range: 10-90% RH, non-condensing
Hysteresis: 10% (typical)
Maximum Terminal Wire Size: 16 AWG
Terminal Torque (typical): 7 in-lbs
Agency Approvals: UL 508 Open Device Listing, CE: EN61010-1:2001-02, CAT III, deg. 2, basic insulation
Product Introduction
Current Monitoring Switch – Adjustable Trip – H308 Applications:
Detect conveyor belt loss, coupling shear, and mechanical faults
Verify runtime of lighting circuits and other electrical services
Monitor status of industrial processing equipment
Monitor status of critical motors (compressors, fuel, etc.)
High-Performance Features
Minimum trip point 0.75A... eliminates multiple wraps of conductor through the sensor, even for loads as small as 1/5 HP
Small size... easy to place in small enclosures
Split-core self-tightening housing for easy installation
Status LED for simple setup and local indication
1 Amp status output for application flexibility
All devices are 100% solid state, non-polarized, with 5-year warranty
Current Monitoring Switch – Adjustable Trip – H308 Specifications:
Sensor Power: Induced from monitored conductor
Insulation Rating: 600VAC RMS (UL), 300VAC RMS (CE)
Frequency Range: 50/60 Hz
Temperature Range: -15° to 60°C
Humidity Range: 10-90% RH, non-condensing
Hysteresis: 10% (typical)
Maximum Terminal Wire Size: 16 AWG
Terminal Torque (typical): 7 in-lbs
Agency Approvals: UL 508 Open Device Listing, CE: EN61010-1:2001-02, CAT III, deg. 2, basic insulation
