Current monitoring switch with relay – adjustable trip - H735
Sensor power: sensed from monitored conductor
Insulation rating: 600VAC RMS
Frequency range: 50/60 Hz
Temperature range: -15° to 60°C (5° to 140°F)
Humidity range: 10-90% RH, non-condensing
Maximum terminal wire size: 14 AWG
Terminal torque (typical): 4 in-lbs (0.45 N-m)
Agency approvals: UL 508 open device listing
Product introduction
Applications of current monitoring switch with relay H735:
Start/stop and monitor motor positive status
Detect conveyor belt loss and coupling shear
Combines fan/circulation pump status sensor and command relay in one package for easy installation.
Reduces component count – fits in small starter kits
Detect conveyor belt loss and motor faults... ideal for fan and circulation pump monitoring
Now one device does two jobs
Reduces electrician costs
Relay and status LED for simple setup
Non-polarized status output
Adjustable current sensor trip setpoint
5-year warranty
Current monitoring switch with relay H735Specifications:
Sensor power: sensed from monitored conductor
Insulation rating: 600VAC RMS
Frequency range: 50/60 Hz
Temperature range: -15° to 60°C (5° to 140°F)
Humidity range: 10-90% RH, non-condensing
Maximum terminal wire size: 14 AWG
Terminal torque (typical): 4 in-lbs (0.45 N-m)
Agency approvals: UL 508 open device listing
