High-Speed Operational Amplifier - MS8052M

The MS805x series are rail-to-rail output voltage feedback operational amplifiers withwith features such as ease of use and low cost. Compared to typical current feedback amplifiers, it has advantages in bandwidth andconversion rate has a greater advantage, and also has a wide input common-mode voltage range andlarge output voltage swing, which allows this series of chips to operate at a low supply voltage as low as2.5Vofuse with a single power supply.Although low cost, the MS805x series chips have excellent overall, it haswhile achieving a large bandwidth of 250MHz (G=+1)0.1dBbandwidth reachesthe37MHz (G=+2), and each amplifier only4.3mAlow power consumption.



1. Features of High-Speed Operational Amplifier - MS8052M:

Low Power Consumption
rail-to-rail output
- 2mV offset voltage
high-speed
-3dB bandwidth (G=+1): 250MHz
- Slew rate: 130V/μs
- 0.1% settling time: 58ns
Operating voltage range: 2.5V to 5.5V
Input voltage range (Vs=5V): -0.2V to +3.8V
excellent video characteristics (RL=150Ω, G=+2)
- 0.1dB gain flatness: 37MHz
- Differential gain error: 0.03%
- Differential phase error: 0.08°
Low Power Consumption
- 4.3mA supply current per amplifier



2. Applications of High-Speed Operational Amplifier - MS8052M:
