ITG Trace Oxygen Sensor O2 Sensor - P-31
This model of oxygen sensor has high reliability, large output signal, and can operate in humidity up to 100%.
Response time is not affected by oxygen concentration, no warm-up time required.
The sensor output is temperature compensated, with fast response time and stable zero point.
It can operate in a pressure range from 1mBar to 1.4bar.
It features no oxygen absorption, electrical isolation, not easily electrolyzed, and long life.
Product Introduction
Trace Oxygen Sensor O2 Sensor P-31Product Features:
This model of oxygen sensor has high reliability, large output signal, and can operate in humidity up to 100%.
Response time is not affected by oxygen concentration, no warm-up time required.
The sensor output is temperature compensated, with fast response time and stable zero point.
It can operate in a pressure range from 1mBar to 1.4bar.
It features no oxygen absorption, electrical isolation, not easily electrolyzed, and long life.
Trace Oxygen Sensor O2 Sensor P-31Applications:
Environmental Monitoring
Municipal Gas
Tobacco Industry
Power Industry
Pharmaceutical Industry
Food Industry
Water Treatment Industry
Petrochemical Industry
Coal
Metallurgy
Trace Oxygen Sensor O2 Sensor P-31Parameters:
| Measurement Range |
100-210000ppm |
| Operating Life |
1 year |
| Signal Output |
315 μA ± 70 μA |
| Resolution |
0.1% |
| Operating Temperature |
-8℃-50℃ |
| Operating Pressure |
600- 1750 hPa |
| Humidity Effect |
0-100%RH |
| Linearity Error |
± 3 % |
| Temperature Compensation |
None |
| Weight |
Approx. 35 g |
| Connection Port |
2-pin PCB connection |
| Response Time |
< 180 s (21%-1000 ppm); <20 min (21%-250 ppm); 1 h (250 ppm to 100 ppm) |
