Oxygen Gas Sensor Alarm for Hypoxia Safety Monitoring in Aluminum Plant Electrolysis Workshops - SKA/O2-BJQ
Detection principle: electrochemical oxygen sensor, natural diffusion sampling
• Detected gas: oxygen O₂
• Range: 0～30%VOL (standard industrial range); optional 0～25%VOL
• Resolution: 0.1%VOL
• Measurement accuracy: ≤±0.5%VOL
• Response time: T90 ≤30s
• Alarm thresholds (customizable, national standard defaults)
◦ Low alarm: 19.5%VOL (oxygen deficiency alarm)
◦ High alarm: 23.5%VOL (oxygen enrichment alarm)
• Sensor lifespan: 2～3 years
Product Introduction
Oxygen Gas Sensor Alarm - Product Overview
The oxygen gas sensor alarm is a gas detection device used for hypoxia safety monitoring in aluminum plant electrolysis workshops. Search keywords: oxygen gas sensor alarm, hypoxia safety monitoring in aluminum plant electrolysis workshops, oxygen alarm. This alarm can continuously monitor the oxygen concentration in the electrolysis workshop. When the concentration falls below the safe value, it emits sound and light alarms and links to the ventilation system. In hypoxia safety monitoring in aluminum plant electrolysis workshops, the oxygen gas sensor alarm can effectively prevent hypoxia risks caused by oxygen consumption during electrolysis and poor ventilation.
Oxygen Gas Sensor Alarm - Working Principle
The oxygen gas sensor alarm uses an electrochemical sensor. It outputs an electrical signal by detecting oxygen concentration, which is then processed by a microprocessor to determine whether to alarm. In hypoxia safety monitoring in aluminum plant electrolysis workshops, the oxygen gas sensor alarm has moisture-proof, dust-proof, and corrosion-proof functions, with a protection rating of up to IP65 or IP67, making it suitable for the high-temperature, strong magnetic field, and corrosive environment of electrolysis workshops. The alarm supports RS485, 4-20mA, and Modbus outputs and can be connected to the workshop safety monitoring system.
Oxygen Gas Sensor Alarm - Application Scenarios
The oxygen gas sensor alarm is widely used in the electrolytic cell area, busbar area, casting area, and personnel inspection passages of aluminum plant electrolysis workshops. In hypoxia safety monitoring in aluminum plant electrolysis workshops, the oxygen gas sensor alarm can be installed near electrolytic cells, ventilation openings, and personnel activity areas. The alarm can be linked with exhaust fans, sound and light alarms, and monitoring platforms to achieve automatic ventilation and alarming. For large-scale electrolytic aluminum plants, the oxygen gas sensor alarm can form a multi-point monitoring network and upload data uniformly to the control center.
Oxygen Gas Sensor Alarm - Technical Advantages
The oxygen gas sensor alarm has advantages such as fast response, good stability, and strong anti-interference ability. In hypoxia safety monitoring in aluminum plant electrolysis workshops, the oxygen gas sensor alarm uses industrial-grade sensors and a corrosion-resistant design, making it suitable for long-term operation. The alarm supports sound and light alarms, remote output, and fault self-check, and is easy to maintain. When selecting an oxygen gas sensor alarm, attention should be paid to detection range, accuracy, response time, protection rating, and output method to ensure reliable and effective hypoxia safety monitoring in aluminum plant electrolysis workshops.
Main Application Areas
- Aluminum Plant Electrolysis Workshops — Continuous oxygen monitoring to prevent hypoxia caused by electrolysis process oxygen consumption and inadequate ventilation.
- Confined Spaces — Oxygen deficiency detection in tanks, silos, and other confined areas to ensure worker safety.
- Chemical Processing Plants — Monitoring oxygen levels in areas where inert gases or chemical reactions may displace oxygen.
- Underground Mines — Oxygen level monitoring in underground mining operations to prevent hypoxia in poorly ventilated tunnels.
- Laboratories — Oxygen concentration monitoring in laboratories using cryogenic gases or conducting oxygen-sensitive experiments.
