German ZF Angular Position Sensor - AN8

1. German ZF Angular Position Sensor AN8 Product Description:

Angular position sensor AN8It is a non-contact, inherently linear contact angular position sensor. It utilizes Hall effect technology and the magnetic field generated by a magnet. The angular displacement of the input shaft causes a linear change in voltage output (proportional to the input voltage).

2. German ZF Angular Position Sensor AN8 Product Features:

High fault-tolerant angular position sensor

Non-contact angular position sensing and full 360° rotation

Customer-customizable for: angle range, slope, PWM output, custom magnets - contact factory

No mechanical interface required, meaning no part wear or jamming

Available with Delphi connector or 12" (305 mm) leads

RoHS compliant

IP67

Air gap size 5.5 mm (0.22")*

3. German ZF Angular Position Sensor AN8 Product Applications:

Position sensing for (forklifts, agricultural trailer suspension, etc.)

Steering, drive-by-wire throttle

Gear selection

Zero-contact encoder replacement

Replacing smart bearings

External trim sensing

4. German ZF Angular Position Sensor AN8 Product Parameters:

Operating temperature	-40 °C to 125 °C (-40 °F to 257 °F)
Storage temperature	-40 °C to 150 °C (-40 °F to 302 °F)
Protection rating	IP67
Input voltage	5.0 VDC ± 10%
Output voltage	10% to 90%
