Siargo Pipeline Mass Flow Meter - MF
Multi-sensor integration on a single chip greatly improves the turndown ratio of this flow meter.
The sensor's zero stability is greatly improved compared to traditional thermal mass flow meters.
Technological advancements have led to structural simplification, significantly reducing pressure loss compared to traditional mechanical instruments, greatly reducing energy consumption.
Equipped with LCD display for instantaneous and cumulative flow, clear and intuitive, easy to read.
This flow meter comes with an RS485 communication module, which can achieve centralized management when connected to a host computer network.
Optional 4-20mA standard current signal output and pulse output.
Passed national explosion-proof certification, marked as Ex ia IIC T4, suitable for flammable and explosive gases.
Product Introduction
I. MF Series Pipeline Mass Flow Meter Product Overview:
The Siargo MF series pipeline mass flow meter is specifically designed for various management and control of industrial gases. This series of instruments can provide intuitive mass flow information, and the user-friendly interface design (RS485/4~20mA/pulse, etc.) allows for easy data processing. This product is suitable for pipes with diameters from 25 to 100mm, with accuracy up to ±(1.5+0.5FS)%, operating ambient temperature of -20 to +60°C, and maximum working pressure of 1.5 MPa. Additionally, our packaging technology ensures the hygienic standards of the flow meter, making it applicable for gas measurement in the beverage and food industry, such as CO2. Furthermore, this product can be widely used in gas measurement and control in other industries, such as special gas monitoring in metallurgy, hydrogen flow monitoring in chemical industry, and monitoring of oxygen, nitrogen, helium, argon, compressed air, etc. during production processes.
II. MF Series Pipeline Mass Flow Meter Product Features:
- Multi-sensor integration on a single chip greatly improves the turndown ratio of this flow meter.
- The sensor's zero stability is greatly improved compared to traditional thermal mass flow meters.
- Technological advancements have led to structural simplification, significantly reducing pressure loss compared to traditional mechanical instruments, greatly reducing energy consumption.
- Equipped with LCD display for instantaneous and cumulative flow, clear and intuitive, easy to read.
- This flow meter comes with an RS485 communication module, which can achieve centralized management when connected to a host computer network.
- Optional 4-20mA standard current signal output and pulse output.
- Passed national explosion-proof certification, marked as Ex ia IIC T4, suitable for flammable and explosive gases.
III. MF Series Pipeline Mass Flow Meter Product Structure and Mechanical Dimensions:
IV. MF Series Pipeline Mass Flow Meter Technical Parameters:
- Accuracy: ±(1.5+0.5FS)%
- Measurement Environment: Temperature (-20~60)°C
- Display Content: Instantaneous flow, cumulative flow
- Data Storage: Instantaneous flow, cumulative flow, total 3000 entries
- Output Modes: 4-20mA; RS485; 5V pulse
- Calibration Conditions: 20°C; 101.325 kPa
- Explosion-proof Rating: ExdiiBT4
- Protection Rating: IP65
V. MF Series Pipeline Mass Flow Meter Product Selection:
