Wireless Wind Speed/Direction Sensor - WSD202-EX

I. Wireless Wind Speed/Direction Sensor WSD202-EX Product Description:

The WSD202 wireless wind speed/direction node is simple and convenient to use. The wireless digital signal transmission eliminates noise interference caused by long cable transmission, and the entire measurement system has extremely high measurement accuracy and anti-interference capability. Wireless sensor nodes can form a large wireless sensor network, supporting up to thousands of measurement points for simultaneous wind speed and direction testing.

The node has a compact structure and small size, consisting of a power module, acquisition processing module, and wireless transceiver module, enclosed in a Ryton PPS plastic housing. The data collected by the node can be transmitted wirelessly to a computer in real time or stored in the node's built-in 1GB data memory, ensuring the accuracy of collected data. The node's over-the-air transmission rate can reach 250K BPS, and the effective outdoor communication distance can reach 100 meters. The node is designed with dedicated power management software and hardware, using a built-in rechargeable battery.

II. Wireless Wind Speed/Direction Sensor WSD202-EX Technical Specifications:

Model	WSD202 (Standard)	WSD202-EX (Long Range)
Number of Channels	Wind direction input channel and wind speed input channel	Wind direction input channel and wind speed input channel
Measurement Range	0-40m/S；0-360°	0-40m/S；0-360°
Sampling Frequency	1Hz	1Hz
Resolution	0.1 m/S	0.1 m/S
Measurement Error	<0.1%	<0.1%
Data Memory Capacity	1GB Flash	1GB Flash
Communication Distance	70 meters line-of-sight	300 meters line-of-sight
Antenna	External antenna	External antenna



III. Wireless Wind Speed/Direction Sensor WSD202-EX Application Fields:

Ship navigation, wind turbines, meteorology, water conservancy and hydrology, port cranes, airports, high-altitude work cranes, etc.
