German EC Sense HCHO formaldehyde sensor - ES1-HCHO-5

Detection principle:

GermanyEC SenseSolid polymer electrochemical detection technology

Sensitivity:

35±20 nA/ppm

Order number:

01-ES1-HCHO-5-01

Temperature range:

-20°CTo50°C

Detection gas:

Formaldehyde gas

Pressure range:

800To1200Hectopascal

Detection range:

0-5ppm

High overload:

100ppm

Resolution:

0.01ppm

Repeatability:

1%

Working principle:

Ampere,3Electrode

Humidity range (non-condensing):

10-95%Relative humidity

Warm-up time:

<20Second

Weight:

<0.7g

Calibration substance:

HCHOStandard gas
