Product Introduction
-
1. Electrochemical Hydrogen Fluoride Sensor (HF Sensor) ME3-HF Product Description
-
The ME3-HF electrochemical gas sensor operates on the electrochemical principle, where the target gas undergoes oxidation-reduction reactions on the working and counter electrodes, releasing charge and generating a current through the external circuit. The current is proportional to the gas concentration, enabling quantitative measurement of the target gas.
-
2. Electrochemical Hydrogen Fluoride Sensor (HF Sensor) ME3-HFSensor Features
-
Low power consumption
High precision
High sensitivity
Wide linear range
Strong anti-interference capability
Excellent repeatability and stability
-
3. Electrochemical Hydrogen Fluoride Sensor (HF Sensor) ME3-HFMain Applications
-
Widely suitable for HF detection in industrial and environmental applications.
-
4. Electrochemical Hydrogen Fluoride Sensor (HF Sensor) ME3-HFTechnical Specifications
| Product Model |
ME3-HF |
| Product Type |
Electrochemical gas sensing element |
| Product Package |
Plastic package (ME3) |
| Detection Range |
0—10ppm |
| Maximum Measurement Limit |
100ppm |
| Expected Life |
2 years |
| Sensitivity |
-0.40±0.15uA/ppm |
| Resolution |
0.1ppm |
| Operating Temperature Range |
﹣20℃～+40℃ |
| Operating Pressure Range |
Standard atmospheric pressure ±10% |
| Response Time (T90) |
≤90S |
| Humidity Range |
15% - 90% RH non-condensing |
| Zero Drift (-20℃～+40℃） |
≤0.2ppm |
| Stability (/month) |
＜2﹪ |
| Load Resistance (Recommended) |
10Ω |
| Repeatability |
<2% of output value |
| Output Linearity |
Linear |
