Product Introduction
Adopts semiconductor sensor, stable and durable.
Range 0~1000ppm, other ranges can also be customized.
High measurement accuracy, up to within ±15%FS, repeatability up to within 2%.
Optional high-quality OLED display, allowing direct on-site reading of values, and clear display even at night.
On-site power supply adopts 10~30V DC wide voltage power supply, which can adapt to various DC power sources on site.
The product adopts a wall-mounted waterproof enclosure, is easy to install, and has a high protection rating, making it suitable for harsh on-site environments.
485 type:
| Power supply | 10~30V DC |
| Output signal | 485 |
| Power consumption | 0.9W |
| Temperature measurement range | -40℃~+80℃ |
| Temperature Accuracy | ±0.5℃（25℃） |
| Humidity measurement range | 0~100%RH |
| Humidity accuracy | ±3%RH（60%RH,25℃） |
| 工作温度 | -20~50℃ |
| Working humidity | 15~90%RH non-condensing |
| Pressure range | 90~110kPa |
| Stability | ≤2% signal value/month |
| Freon zero drift (-20~40℃) | ±3%FS |
| Repeatability | ≤2% |
| Service life | ≥12 months |
| Measuring range | 0~1000ppm |
| Accuracy | ±15%FS（@R22，500ppm、25℃、50%RH） |
| 分辨率 | 1ppm |
| Response time | ≤35s |
| Preheating Time | ≥24h |
Analog type:
| Power supply | 10~30V DC |
| Output signal | 4-20mA、0-5V、0-10V |
| Power consumption | 0.9W |
| 工作温度 | -20~50℃ |
| Working humidity | 15~90%RH non-condensing |
| Pressure range | 90~110kPa |
| Stability | ≤2% signal value/month |
| Freon zero drift (-20~40℃) | ±3%FS |
| Repeatability | ≤2% |
| Service life | ≥12 months |
| Measuring range | 0~1000ppm |
| Accuracy | ±15%FS（@R22，500ppm、25℃、50%RH） |
| 分辨率 | 1ppm |
| Response time | ≤35s |
| Preheating Time | ≥24h |
WiFi type:
| Power supply | 10~30V DC |
| Power consumption | 0.9W |
| Temperature measurement range | -40℃~+80℃ |
| Temperature Accuracy | ±0.5℃（25℃） |
| Humidity measurement range | 0~100%RH |
| Humidity accuracy | ±3%RH（60%RH,25℃） |
| 工作温度 | -20~50℃ |
| Working humidity | 15~90%RH non-condensing |
| Pressure range | 90~110kPa |
| Stability | ≤2% signal value/month |
| Freon zero drift (-20~40℃) | ±3%FS |
| Repeatability | ≤2% |
| Service life | ≥12 months |
| Measuring range | 0~1000ppm |
| Accuracy | ±15%FS（@R22，500ppm、25℃、50%RH） |
| 分辨率 | 1ppm |
| Response time | ≤35s |
| Preheating Time | ≥24h |
| WIFI communication parameters | 802.11b/g/n |
| Security | Security mode WEP/WPA-PSK/WPA2-PSK Encryption type WEP/TKIP/AES |
| Configuration tool | "Bluetooth Tap-to-Configure" |
LORA type:
| Power supply | 10~30V DC |
| Output signal | LORA |
| Power consumption | 0.9W |
| Temperature measurement range | -40℃~+80℃ |
| Temperature Accuracy | ±0.5℃（25℃） |
| Humidity measurement range | 0~100%RH |
| Humidity accuracy | ±3%RH（60%RH,25℃） |
| 工作温度 | -20~50℃ |
| Working humidity | 15~90%RH non-condensing |
| Pressure range | 90~110kPa |
| Stability | ≤2% signal value/month |
| Freon zero drift (-20~40℃) | ±3%FS |
| Repeatability | ≤2% |
| Service life | ≥12 months |
| Measuring range | 0~1000ppm |
| Accuracy | ±15%FS（@R22，500ppm、25℃、50%RH） |
| 分辨率 | 1ppm |
| Response time | ≤35s |
| Preheating Time | ≥24h |
Main Application Areas
- Smart Homes — Real-time refrigerant leak detection to ensure indoor air safety and HVAC efficiency.
- Automotive & Transportation — Monitors Freon levels in vehicle air conditioning systems and transport refrigeration units.
- Garages & Workshops — Detects refrigerant leaks in automotive repair shops and industrial maintenance areas.
- Chemical Plants — Continuous monitoring of refrigerant gases in chemical processing and storage facilities.
- Enclosed Living Spaces — Provides early warning of refrigerant accumulation in basements, cabins, and sealed rooms.
