UK GSS Low Power Compact Miniature Infrared CO2 Sensor (NDIR CO2 Sensor) - MINIR/ExplorIR-M

I.Infrared CO2 Sensor/CO2 Sensor MINIR/ExplorIR-M Product Description:

Infrared CO2 Sensor/CO2 SensorMINIR is a low power (3.5mW) and high performance CO2 sensor, ideal for battery-powered products and portable devices; based on IR LED technology and innovative optical path design, making the CO2 sensor MINIR a low power, compact NDIR sensor; MINIR is GSS's third-generation product and an innovator in IR LED CO2 sensing technology.

II. Infrared CO2 Sensor/CO2 Sensor MINIR/ExplorIR-M Product Features:

Ultra-low power 3.5mW
Measurement range from 0 to 100%
Supply voltage 3.3V
Peak current only 33mA
20mm diameter probe-style package

III. Infrared CO2 Sensor/CO2 Sensor MINIR/ExplorIR-M Applications

Storage of vegetables and fruits, chemical industry, bacteria incubators, industrial, medical

IV. Infrared CO2 Sensor/CO2 Sensor MINIR/ExplorIR-M Product Parameters:

Warm-up time	<10s. 1.2S output CO2 concentration value
Operating environment	0℃ ~50℃ (standard) 0 ~ 95%RH, non-condensing
Storage temperature	-30℃ ~ +70℃
Sensing method	Non-dispersive infrared absorption technology, Gold-plated optical path patented technology, All-solid-state light source and detector patented technology
Sampling method	Gas diffusion
Measurement range	0-5%， 0-20%， 0-60%， 0-100%
Accuracy	±70ppm or +/-5% of reading, whichever is greater
Non-linearity	<1%FS
Operating pressure range	950mbar~ 1050mbar
Response time	10 seconds to 3 minutes, readings twice per second
Power input	3.25V to 5V (3.3V recommended) Peak current 33mA, average current <1.5mA
Power consumption	3.5mW
