Hall Current Sensor - AH810S

AH810S is a monolithic programmable Hall-effect linear sensor manufactured using advanced BCD technology. It integrates a high-sensitivity Hall sensor, high-precision Hall temperature compensation unit, Hall signal pre-amplifier, oscillator, dynamic offset cancellation circuit, and amplifier output module, providing customers with a more effective AC/DC current detection solution, widely applicable to communication, industrial, and consumer electronic devices.

AH810S adopts overcurrent protection, high-bandwidth dynamic offset cancellation technology. In the absence of a magnetic field, the static output is a fixed 2.5V. The integrated dynamic offset cancellation circuit makes the IC's sensitivity unaffected by external pressure and IC package stress.

The output voltage of AH810S is proportional to the applied magnetic field strength. Users can program the sensitivity and static (zero-field) output voltage via the power supply pin to improve product performance in applications.

The static output voltage of AH810S is adjustable in the range of 2.5V±0.2V, and the output sensitivity is adjustable from 1.8 to 30mV/Gs.

I.Hall Current Sensor -Features of AH810S:

Monolithic Programmable
Accuracy (typical): ±1mV @25℃;
High Linearity: ±0.1% @25℃;
High Bandwidth: 120kHz;
Output Response Time: 4μs (typical);
Stability over Operating Range: 1.5% @25℃～150℃; 1% @-40℃～25℃;
Fixed VOUT 2.5V output;
Fixed VREF output 2.5V
Low noise analog signal path;
Strong anti-interference capability;
High resistance to mechanical stress; magnetic parameters do not shift due to external pressure;
ESD (HBM) 5kV；
Operating temperature: -40℃～150℃;
RoHS compliant: (EU) 2015/863.

II.Hall Current Sensor -Applications of AH810S:

Inverter current detection

Motor phase current detection (motor control)

Photovoltaic inverters

Battery load detection systems

Current transformers

Switching power supplies

Overload protection devices
