185. PID sensor TVOC detection photoionization sensor - 4PID-10000-3.3V
186. Working principle: Photoionization detector
187. Detection range: 0~10000ppm
188. Resolution: 200ppb
189. Repeatability accuracy: <±2% (calibration point)
190. Operating temperature range: -40~50°C
191. Operating humidity range: 0~99%RH (non-condensing)
192. Operating pressure range: 800~1200 mbar
196. Product introduction
197. 1. Description of PID sensor TVOC detection photoionization sensor 4PID-10000-3.3V:
198. It is a photoionization sensor composed of a vacuum ultraviolet lamp, a high-sensitivity low-noise detection circuit, and a miniature ionization chamber. It can provide a detection range of up to 10000ppm and a detection limit as low as 0.1ppb. The standard 4-series compact design makes it easy to apply in various handheld portable, field fixed instruments, and also in various types of analytical instruments.
199. 2. Features of PID sensor TVOC detection photoionization sensor 4PID-10000-3.3V:
200. Extremely fast response speed
201. Extremely high resolution
202. 3. Applications of PID sensor TVOC detection photoionization sensor 4PID-10000-3.3V:
203. Detection of most volatile organic compounds
204. Detection of some inorganic vapors
205. Environmental protection
206. Widely used in petrochemical and other fields
207. 4. Parameters of PID sensor TVOC detection photoionization sensor 4PID-10000-3.3V:
| 208. Basic characteristics |
|
| 209. Working principle |
210. Photoionization detector |
| 211. Detection range |
0~10000ppm |
| 212. Resolution |
200ppb |
| 213. Repeatability accuracy |
214. <±2% (calibration point) |
| 215. Operating temperature range |
-40~50°C |
| 216. Operating humidity range |
217. 0~99%RH (non-condensing) |
| 218. Operating pressure range |
800~1200 mbar |
| 219. Electrical characteristics |
|
| 220. Operating voltage |
3.3±0.3V |
| 221. Operating current |
30~50mA |
| 222. Output signal |
223. 0.05 V~input voltage |
| 224. Safety certification |
Pending |
| 225. Lifetime |
|
| 226. Recommended storage temperature |
0~20℃ |
| 227. Normal service life |
228. More than 36 months in air |
| 229. UV lamp life |
230. 24 months |
| 231. Warranty |
232. 12 months |
233. 5. PID sensor TVOC detection photoionization sensor4PID-10000-3.3V234. Model selection:
| 235. Product classification & performance classification (10.6eV)-3.3V |
|||||
| 236. Range |
20ppm |
100ppm |
1000ppm |
5000ppm |
10000ppm |
| 237. Part Number |
135-000-020 |
135-000-120 |
135-000-130 |
135-000-530 |
135-000-140 |
| 238. Resolution |
1ppb |
5ppb |
50ppb |
100ppb |
200ppb |
| 239. Sensitivity |
＞75mV/ppm |
＞15mV/ppm |
＞1.5mV/ppm |
＞0.3mV/ppm |
＞0.15mV/ppm |
| 240. Response time (T90) |
≤5second |
≤5second |
≤3second |
≤3second |
≤3second |
