PID sensor TVOC detection photoionization sensor - 4PID-5000-3.3V

1. PID sensor TVOC detection photoionization sensor 4PID-5000-3.3V description:

It is a photoionization sensor composed of a vacuum ultraviolet lamp, high-sensitivity low-noise detection circuit, and micro ionization chamber, capable of providing a detection range up to 10000ppm and a minimum detection limit of 0.1ppb. The standard 4-series compact design makes it easy to apply in various handheld portable, field fixed instruments, and also in various types of analytical instruments.

2. PID sensor TVOC detection photoionization sensor 4PID-5000-3.3V features:

Extremely fast response speed

Extremely high resolution

3. PID sensor TVOC detection photoionization sensor 4PID-5000-3.3V applications:

Most organic volatiles

Detection of some inorganic vapors

Environmental protection

Widely used in petrochemical and other fields

4. PID sensor TVOC detection photoionization sensor 4PID-5000-3.3V parameters:

Basic characteristics
Working principle	Photoionization detector
Detection range	0~5000ppm
Resolution	100ppb
Repeatability accuracy	<±2% (calibration point)
Operating temperature range	-40~50°C
Operating humidity range	0~99%RH (non-condensing)
Operating pressure range	800~1200 mbar
Electrical characteristics
Operating voltage	3.3±0.3V
Operating current	30~50mA
Output signal	0.05 V~input voltage
Safety certification	Pending
Lifetime
Recommended storage temperature	0~20℃
Normal service life	Greater than 36 months in air
UV lamp life	24 months
Warranty	12 months

5. PID sensor TVOC detection photoionization sensor 4PID-5000-3.3V model selection:

Product classification & performance classification (10.6eV)-3.3V
Range	20ppm	100ppm	1000ppm	5000ppm	10000ppm
Part Number	135-000-020	135-000-120	135-000-130	135-000-530	135-000-140
Resolution	1ppb	5ppb	50ppb	100ppb	200ppb
Sensitivity	＞75mV/ppm	＞15mV/ppm	＞1.5mV/ppm	＞0.3mV/ppm	＞0.15mV/ppm
Response time (T90)	≤5second	≤5second	≤3second	≤3second	≤3second
