Product Introduction
Range 0-5ppm, other ranges can also be customized;
Adopts an electrochemical sensor and features high measurement accuracy, fast response speed, long service life, and long-term stability and reliability;
The device output resolution can reach 0.01ppm and supports long-term 24-hour online monitoring;
Adopts anti-interference circuit design, able to withstand various strong electromagnetic interference on site such as variable frequency drives;
Optional high-quality OLED display, allowing direct on-site reading of values, and clear display even at night.
| Power supply | 10~30V DC (0~10V output type can only be powered by 24V) | ||||
| Output signal | 4~20mA、0~5V、0~10V | ||||
| Power consumption | 0.12W | ||||
| Temperature measurement range | -40℃~+80℃ | ||||
| Humidity measurement range | 0~100%RH | ||||
| Temperature Accuracy | ±0.5℃ | ||||
| Humidity accuracy | ±3%RH | ||||
| 工作温度 | -20~50℃ | ||||
| Working humidity | 15~90%RH non-condensing | ||||
| Pressure range | 91~110kPa | ||||
| Stability | ≤7% signal value/year | ||||
| Response time | ≤35s | ||||
| Preheating Time | ≥5min | ||||
| Formaldehyde zero drift (-20~40℃) | ≤±0.5ppm | ||||
| Repeatability | ≤2% | ||||
| Service life | ≥24 months | ||||
| Accuracy | Accuracy: ±5%FS （@1ppm、25℃、50%RH） |
||||
| 分辨率 | 0.01ppm |
Main Application Areas
- Indoor Air Quality Monitoring — Measures formaldehyde levels in HVAC ducts to ensure safe indoor air quality in buildings.
- Industrial Process Control — Monitors formaldehyde concentration in industrial pipelines for process optimization and safety.
- Environmental Monitoring — Used in environmental stations to detect formaldehyde emissions from industrial sources.
- Laboratory Research — Provides accurate formaldehyde measurement for scientific experiments and studies.
- Chemical Industry — Ensures safe formaldehyde levels in chemical production and storage areas.
Keywords：duct formaldehyde transmitter, CH2O sensor, pipeline formaldehyde monitor, electrochemical formaldehyde sensor, industrial formaldehyde detector, duct gas transmitter, formaldehyde concentration meter, AMT/RS-CH2O
