The temperature and humidity measurement unit is imported from Switzerland, ensuring accurate measurement;


PM2.5 and PM10 are collected simultaneously, with a range of 0-1000μg/m³ and a resolution of 1μg/m³. The unique dual-frequency data acquisition and automatic calibration technology ensures consistency of up to ±10%;


The gas unit uses an electrochemical sensor, which has excellent sensitivity and repeatability;


The air pressure range is a wide range of 0-120kPa, which can be applied to various altitudes;


The TVOC measurement unit adopts imported high-sensitivity gas detection probes from abroad, with mature technology, and uses high-performance signal acquisition circuits, ensuring stable signals and high accuracy.

DC Power Supply (Default)	DC 10-30V
Maximum power consumption	WIFI type: 1.6W (24V DC power supply)
	4G type: 1.6W (24V DC power supply)
	RS485 type: 1.5W (24V DC power supply)
	ETH type: 1.6W (24V DC power supply)
Detection parameters	Temperature, humidity, PM2.5, PM10, TSP, atmospheric pressure, light, noise, odor, TVOC, CO2, formaldehyde, O3、CO、O2、SO2、NO2、H2、H2S、NH3, smoke
Working Environment	Temperature -10℃-55℃; Humidity 0~95%RH non-condensing TSP element: Temperature -10℃-55℃; Humidity 0~70%RH
信号输出	RS485 output (standard ModBus-RTU protocol)
	4G Wireless Transmission
	WIFI Wireless Transmission
	RJ45 network port upload, supports static IP address, automatic IP address acquisition function, supports cross-gateway, domain name resolution
Product material	ABS
安装方式	Wall-mounted, ceiling-mounted

Table 2:

Detection parameters	Measuring range	分辨率	Accuracy	Preheating Time
PM2.5	0~1000μg/m3	1μg/m3	Particle counting efficiency: 50%@0.3μm，98%@>=0.5μm。 PM2.5 accuracy: ±3%FS (@100μg/m3、25℃、50%RH）	≤2min
PM10	0~1000μg/m3
TSP	0~20000μg/m3	1μg/m3	±25% or ±40μg/m3Take the larger value (@1000μg/m3，25℃,50%RH）
TSP (high precision)	0~20000μg/m3	1μg/m3	±20% or ±30μg/m3Take the larger value (@1000μg/m3，25℃,50%RH）
Temperature	-40℃~+120℃, default -40℃~+80℃	0.1℃	±0.5℃(25℃）
Humidity	0%RH-100%RH	0.1%RH	±3%RH（60%RH,25℃）
Atmospheric pressure	0~120kPa	0.1kPa	±0.15kPa@25℃101kPa
Illuminance	0~200,000 Lux	1Lux	±7%(25℃)
TVOC	0~60000ppb	1ppb	Typical accuracy:8%FS(@C4H8，50000ppb，25℃，50%RH)	≥24H
Carbon dioxide	0-5000ppm (effective range: 400-5000ppm)	1ppm	±(50ppm+ 3%F·S) @(25℃、400~5000ppm)	2min (usable), 10min (maximum accuracy)
Formaldehyde	0~5ppm	0.01ppm	Accuracy: ±5%FS (@1ppm, 25℃, 50%RH)	≥5 minutes
Ozone	0~10ppm	0.01ppm	Accuracy: ±6%FS (@5ppm, 25℃, 50%RH)	≥5 minutes
O2	0~30%VOL	0.1%VOL	±2%FS	≥5 minutes
H2S	0~100ppm	1ppm	±2ppm or ±10%	≥5 minutes
CO	0~1000ppm	1ppm	±5ppm or ±10%	≥5 minutes
NO2	0~20ppm	0.1ppm	±5%FS	≥5 minutes
SO2	0~20ppm	0.1ppm	±5%FS	≥5 minutes
H2	0~1000ppm	1ppm	±5%FS	≥5 minutes
NH3	0~100ppm	1ppm	±8%	≥5 minutes
Noise	30~130dB	0.1dB	±0.5dB (at reference pitch, 94dB@1kHz)
Odor (electrochemical type)	0~5ppm	0.001ppm	Typical accuracy: ±10%FS (@H2S，5ppm）	≥5 minutes
Odor (high precision)	0~5ppm	0.001ppm	Typical accuracy: ±5%FS (@H2S，500ppb）	≥5 minutes
Odor (semiconductor type)	0.03~3ppm	0.001ppm	±13%FS（@C2H6O，5ppm,20℃，65%RH）	≥60 minutes
Smoke	0~10000ppm	1ppm	±5%FS（@C3H8，2000ppm、25℃、50%RH）	≥24H

Dimensions:

Dimensions: mm
