Submersible Liquid Level Sensor Groundwater Well Liquid Level Monitoring - AMT/LD-YWJ
Measuring range: 0～5m (optional 0~10m)
• Accuracy: ±0.25%FS
• Resolution: 1mm
• Probe material: 316L stainless steel, optional PTFE anti-corrosion diaphragm
• Signal output: 4～20mA (2-wire); optional RS485 Modbus
• Power supply: DC24V
• Medium temperature: 0～80℃
• Working pressure: normal pressure
• Display: Optional matching secondary display instrument
• Warranty: 1 year
Product Introduction
Submersible Liquid Level Sensor Groundwater Well Liquid Level Monitoring - Product Overview
A submersible liquid level sensor is a contact-type liquid level detection device based on the hydrostatic principle. Search keywords: submersible liquid level sensor, groundwater well liquid level monitoring, liquid level sensor. The sensor can be directly put into water to measure liquid level height, and is suitable for groundwater wells, pools, water tanks, and rivers. In groundwater well liquid level monitoring, submersible liquid level sensors can operate stably over the long term, reflect water level changes in real time, and help with hydrological monitoring and water resource management.
Submersible Liquid Level Sensor Groundwater Well Liquid Level Monitoring - Working Principle
Submersible liquid level sensors use the principle that hydrostatic pressure is proportional to liquid level height, detecting water pressure through a pressure-sensitive element and then converting it into liquid level height. In groundwater well liquid level monitoring, submersible liquid level sensors use stainless steel or PVC housings, with protection ratings up to IP68, making them suitable for long-term immersion. The sensor supports 4-20mA, RS485, and Modbus outputs, can be connected to data acquisition instruments and remote monitoring platforms, and has temperature compensation and lightning protection functions.
Submersible Liquid Level Sensor Groundwater Well Liquid Level Monitoring - Application Scenarios
Submersible liquid level sensors are widely used in groundwater monitoring wells, reservoirs, rivers, pools, water tanks, and other locations. In groundwater well liquid level monitoring, submersible liquid level sensors can be suspended or fixed inside the well, and cable length can be customized according to well depth. The sensor can work in conjunction with data acquisition terminals and cloud platforms to achieve automatic water level recording and alarms. For remote areas, submersible liquid level sensors can also use battery power and wireless transmission.
Submersible Liquid Level Sensor Groundwater Well Liquid Level Monitoring - Technical Advantages
Submersible liquid level sensors have the advantages of high precision, good stability, and convenient installation. In groundwater well liquid level monitoring, submersible liquid level sensors use a fully sealed structure and corrosion-resistant materials, making them suitable for long-term immersion in water. The sensor supports remote calibration and fault self-diagnosis, making maintenance convenient. When selecting a submersible liquid level sensor, attention should be paid to the measuring range, accuracy, pressure resistance, cable material, and output signal to ensure it meets the needs of groundwater well liquid level monitoring.
Main Application Areas
- Groundwater Well Monitoring — Provides continuous, stable measurement of water level changes in groundwater wells for hydrological monitoring and water resource assessment.
- Water Tanks and Reservoirs — Enables accurate level measurement in water storage tanks and reservoirs for industrial and municipal water management.
- Rivers and Open Channels — Suitable for monitoring water levels in rivers, streams, and open channels to support flood warning and environmental monitoring.
- Wastewater Treatment — Used in wastewater treatment plants for level control in tanks, sumps, and aeration basins.
- Pumping Stations — Helps automate pump control by providing reliable level feedback in pumping stations and lift stations.
Keywords：submersible level sensor, groundwater level sensor, liquid level transmitter, water level sensor, hydrostatic level sensor, well water level monitor, 4-20mA level sensor, RS485 level sensor
